Dear Kubernetes: You need to get your priorities straight

Editor’s note: I’ve been informed that the introduction to this post is convoluted and confusing. If you’d like, feel free to skip it go straight to the first subsection.

When I was in grad school, I spent a LOT of time thinking about mixed integer programming; in fact, my PhD thesis was primarily focused on developing new techniques for solving (certain classes of) integer programs). In short, if you’re unfamiliar with this concept, an “integer program” is just a system of equations that encodes certain “state” as variables that can only take certain (integer) values. The goal is to find the “best” set of assignments to those variables so as to maximize some objective or goal.

See, the thing is, though, integer programming is hard. Like, really hard. Like, as hard as a lot of other really hard problems. And so when you’re confronted with one of these problems, one of the things you might do is “try to make it easier”. For mixed-integer programming, one of the ways you can make things easier is called the “Big-M Method”. The idea is, “Well, OK, it’s really hard to find integer solutions to the equation $x = y$, but maybe instead we can replace that equation with $x - y \leq Mz$ and $x - y \geq Mz$ for some other variable $z$ and some extremely large constant $M$”.

The problem with this approach is that $M$ has to be “big enough” so that your solver can’t “cheat” and find a solution to these equations where $x \neq y$. BUT, and this is the important piece for the rest of this entire post, which I promise is relevant, the bigger you make $M$, the harder the problem is to solve in practice, specifically because $M$ doesn’t have any meaning or relationship to the problem you’re actually trying to solve¹. And therein lies the problem with Kubernetes.

Weight, weight, don’t tell me

So I’m pretty sure at least all of you are going “WTF is drmorr on about today?” and are ready to ragequit your browser. But if you bear with me² I promise I’ll make it all make sense.

Let’s back up. I work on this extremely complex distributed system called “Kubernetes”. And because Kubernetes wants to be all things for all people, there are a lot of different ways that any individual user can configure Kubernetes. And in many cases it is impossible³ for the authors of Kubernetes to know how end users might want to configure Kubernetes; questions like “is this thing more important than that thing?” might reasonably have different answers for different people. And whenever we run into one of those questions, instead of doing the hard work of understanding our customers, we just do the distributed-systems equivalent of Big-M and say “Screw it, we’ll just slap a priority on that sucker and let the users decide.”

Here is a (non-exhaustive) list of where I’ve encountered this behaviour:

• The kube-scheduler scoring step: kube-scheduler operates on pods one-at-a-time⁴, and for each pod it goes through a long pipeline which first filters out nodes that the pod can’t schedule on, and then scores the remaining nodes. There are a lot of different tests that are run to compute the score of a node: things like “how many pods are already on the node”, “how many resources would be left on the node if the pod gets scheduled there”, “are there any ‘soft’ affinity or anti-affinity rules in play”, etc. Now the thing is that each of these tests are weighted, and the weight controls how much the test contributes to the final score. And of course, because different users might have different goals and priorities, these weights are user-configurable.
• The Cluster Autoscaler priority expander: Same deal as kube-scheduler, different problem. Cluster Autoscaler needs to pick one of $N$ different node groups to scale up when there are pending pods in the cluster; it first filters out the invalid ones and then selects the node group based on a weighted rank of the remainder. This one’s fun because in 98% of cases, it reduces to “picking the first entry in a sorted list”; the values of the weights are completely irrelevant.
• The Pod Priority mechanism: Kubernetes allows you to specify priorities on your pods themselves, so that if there isn’t enough space in your cluster for a pending pod and it’s a higher priority than another (currently running) pod, the lower-priority pod will get evicted and the higher-priority pod can then take up the newly-freed slot⁵. This one’s particularly fun because setting pod priorities can have unintended knock-on effects to your pod’s QoS class.
• Pod Deletion Cost annotations: If you didn’t want just one way of setting pod priorities, don’t worry, here’s another! You can set the controller.kubernetes.io/pod-deletion-cost annotation on your pods to tell Kubernetes, hey, when my ReplicaSet scales down, delete the pods with lower deletion cost before the ones with higher deletion cost! As a fun bonus, Karpenter’s balanced consolidation mode also now relies on this annotation to determine the cost of consolidating a node.

I’m sure there are others, but these are ones that I’ve personally interacted with (and been bitten by) in the past. The problem in each of these cases is the same as the Big-M problem in integer programming: these numeric weights a) have no meaning except that which is assigned by the users of the system, b) changing the value of the weights can have unintended consequences in distant parts of the system, and c) the temptation is to make these weight values really, really large to signal “Hey this thing is REALLY IMPORTANT, don’t touch it”, and bigger numbers = bigger problems.

Let’s look at a couple of examples.

Example 1: kube-scheduler node scoring

The first example of how this can bite you is in kube-scheduler; here, the weights are being applied to the different tests that kube-scheduler executes as part of node scoring. Let’s imagine that there are five different such tests. For our purposes, a test $T_i$ is a real-valued function that takes some arbitrary inputs about the state of the cluster and the node under consideration; in other words, in math-y lingo, $T_i: \mathcal{K} \times n \to \mathbb{R}$.

Each test is then given a user-specified weight $w_i \in \mathbb{R}$, and the score for a particular node in the cluster is calculated as the weighted sum of the tests evaluated for that node. Moreover, the selected node is the one that maximizes this weighted sum:

$$\max_n w_1 T_1(\mathcal{K}, n) + w_2 T_2(\mathcal{K}, n) + w_3 T_3(\mathcal{K}, n) + \\ w_4 T_4(\mathcal{K}, n) + w_5 T_5(\mathcal{K}, n)$$

Now, let’s suppose as the administrator of the cluster, you want to ensure that pods always get scheduled on cheaper nodes before they get scheduled on more expensive nodes⁶. Let’s say that $T_5$ returns the cost of the node, so you set $w_5$ to the largest negative number you can think of, say, -100. Then you go about your day, and all of a sudden you get paged because some pod got scheduled to an expensive node before a cheap node! What! How can this be???

Well, in this example, you didn’t care about any of the other tests, so you just left $w_1,...,w_4 = 1$. Each of the other tests $T_1,...,T_4$ returns the value 300, and since the expensive node of course costs $10, the final node score is 200. Turns out that for all the other (cheaper) nodes, the other tests returned 1, so the weighted sum for those nodes was -96.

“Well, ok, that can’t be right,” I hear you say from all the way over here. “Lemme just adjust some of those other weights real quick!” And bam! You have just entered the 12th circle of hell without even realizing it.

Example 2: pod deletion cost and balanced consolidation

In the previous example, there is a single hypothetical user that is controlling all of the numeric weights. So even though the weights don’t have any semantic meaning to the system, there is a single user that can assign some semantic meaning to their choices. This second example is more insidious, because it involves multiple users with competing incentives getting to pick the weights.

In Karpenter 1.14, the Balanced Consolidation disruption mode was introduced. The high-level idea here is that Karpenter shouldn’t disrupt nodes where the benefits don’t outweigh the drawbacks. Since Karpenter’s whole shtick is “save money”, the authors used “the amount you would save by disrupting the node” for the “benefit” side of that equation. On the “drawbacks” side of the equation is “how much disruption does this cause”, and the entire calculation boils down to comparing the “benefits / disruption” ratio to 2.

The problem is that the “disruption” part of this ratio is (essentially) just a weighted sum of the pods on the node, and the owners of the pods (who may or may not be on the same team, and who may or may not have an antagonistic relationship towards each other) get to set those weights, via the pod-deletion-cost annotation. So if engineers on one team see their pods getting frequently disrupted by Karpenter, they’re going to increase the weight of those pods so that some other team of losers gets their pods disrupted instead. And then that other team is going to play a tit-for-tat game until both teams have set their deletion costs to INT_MAX and are furious with each other, and congratulations, you’re back in the 12th circle of hell⁷.

Who could have foreseen this?

I’d like to argue in this post that the underlying cause of all these problems (including the Big-M problem at the beginning of the post) boils down to two factors:

1. Allowing (essentially) unbounded range on your weights
2. Using unit-less values for your weights

The first problem is somewhat obvious: allowing big numbers means there is always the temptation to just say “well THIS thing is really important, so lemme 10x the weight!” And then later on when the math fails you, you go and 10x some other really important thing, and the cycle continues ad infinitum.

The second problem I think is more fundamental. You’re trying to compare fundamentally incomparable things by assigning them numeric weights. You, as the external operator, give those weights some semantic meaning, but math doesn’t know what that semantic meaning is: all math sees is numbers, and numbers are easy to compare⁸! The “right” answer here is “don’t compare incomparable things” but I admit that isn’t always practical, so my second-place recommendation is to always make sure the things you’re comparing have units. As we all learned in physics class, unitless numbers are bad.

For example, in the Karpenter balanced consolidation case, an arguably “better” notion of disruption might be something like “time needed to get all the pods on the node back to Running”. Then you can consider the ratio of “dollars saved / time spent rescheduling”, and that lets you start to semantically-encode some of your external priorities into your policy engine. It might be fine to spend 2 minutes rescheduling all the pods if you’re going to save $100, but if you’re only going to save 50 cent, it might not be worth it⁹.

My last suggestion here is, if you do have to make up some unitless integer weights, consider dramatically constraining the range of values those weights can take on. Nobody can reason about the difference between something with weight 147938964 and 147938965, but people can actually think about the difference between, say, 1 and 3. And as a corollary to this, if you find that you only need a few weight values, maybe see if you can get that number down to two, because then you can replace it with a boolean: I claim that nobody ever needs to set a pod deletion cost in [-2147483648, 2147483647]. All anybody ever actually cares about is “delete these pods first, then delete those ones”, which is just two states.

In closing, just remember, kids: the next time you think about adding in a user-configurable integer weight value to your distributed system (or your integer program), “Dr. Morr says NO!”

As always, thanks for reading.

~drmorr
